HOWO Used Concrete Mixer Truck

Truck Model

ZZ5257GJBN3847W

Type of Vehicle

10m3 Concrete Mixer Truck

Truck Brand

SINOTRUK—HOWO

Driving Position

Left Hand Driving

Total Weight

25,000kg

Curb Weight

10580

Max speed(km/h)

78

Color

Optional

Chassis & Add Components

Frame Details

parallel ladder with U-profiles and   riveted cross members

Dimension(Lx W xH)(unloaded)(mm)

9040x2496x3980

Approaching angle/Departure angle(°)

19/22

Overhang(front/rear) (mm)

1500/2365

Wheel base (mm)

3825+1350

Engine

Model

WD615.47

Power

371hp

Emission

EURO II

Type

water-cooled,four strokes,6 cylinders in   line,turbocharged, directly injection

Kind of Fuel

Diesel

Clutch & Gear Box System

Clutch

SINOTRUKΦ430mm diaphragm spring clutch

Gear Box

HW19710,10 forwards and 2 reverse.

Axles

Front Axle Model

HF9

Rear Axle

HC16

Electrical System

Battery

2X12V/165Ah

Alternator

28V-1500w

Starter

7.5Kw/24V

Brake System

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating   on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

8118

Wheels & Tyres

Type

12.00R20

Material

Tubeless tire

Quantity

10+1 spare

Cabin

Type

HW76 standard cabin

single sleeper, with air-condition

all-steel forward   control,55ºhydraulically tiltable to the front

arm windscreen wiper system with three   speeds,
